| Max Drilling Diameter | Ø16mm(5/8’’) |
| Motor Power | 375/450/550w |
| Chuck Capacity | 3~16mm |
| Spindle Travel | 80mm |
| Class Of Speed | 16 |
| Speed50/60Hz | 210~2220/220~3320 rpm |
| Spindle Taper | MT2 |
| Max distance from spindle axis to surface of column | 162.5mm |
| Max distance from spindle end to surface of table | 450mm |
| Max distance from spindle end to surface of base | 630mm |
| Swing | 325mm |
| Table Size | Ø290mm |
| Base Size | 420×250mm |
| Column Diameter | Ø72mm |
| Height | 980mm |
| Net Weight/ Gross Weight | 42.0/45.0kg |
| Packing Size | 770×450×260mm |
