| Max Drilling Diameter | Ø16mm(5/8’’) |
| Motor Power | 375/450/550w |
| Chuck Capacity | 3~16mm |
| Spindle Travel | 60mm |
| Class Of Speed | 12 |
| Speed50/60Hz | 300~2550/360~3060 rpm |
| Spindle Taper | MT2 |
| Max distance from spindle axis to surface of column | 155mm |
| Max distance from spindle end to surface of table | 490mm |
| Max distance from spindle end to surface of base | 610mm |
| Swing | 310mm |
| Table Size | Ø260mm |
| Base Size | 420×250mm |
| Column Diameter | Ø58mm |
| Height | 900/950mm |
| Net Weight/ Gross Weight | 34.0/36.0kg |
| Packing Size | 770×450×260mm |
